In one sentence, the goal of the Scarab project is to develop an easy to use issue tracking system primarily using Java based technologies. To break this up, there are actually multiple goals to the Scarab project that can fall under different categories.

• Design and Architecture
• Database Schema
• Usability

We choose Java based technologies for a few reasons. The first is that CollabNet developers are primarily interested in Java Servlets for developing web applications. Servlets have many advantages over other technologies. They are fast, stable, portable and easy to write. There are other languages such as Python and Perl that are also popular and we hope that people will choose to use the Scarab schema as the basis for developing their own front end applications. Just because we have chosen Java does not mean that we are adverse to seeing Scarab implemented in multiple different environments, it is just we needed to make a decision and our first decision and priority is Java. :-)

We are not interested at this point in getting into language wars. We chose Java and Java Servlets because they are a widely used technology that has been proven to work in large scale systems. As stated above, we feel that designing a solid schema foundation will allow anyone to port the UI front end of Scarab to any other language. In fact, we are encouraging this.

Servlets by nature allow developers an easy way to create systems that can run on multiple platforms. By default, Scarab will run equally and without code changes on both Win32 and Unix systems. In fact, primary development is happening on my Win32 box (and now my MacOS X box) using the Tomcat 4.0 servlet engine. Scarab will also run without modifications in any servlet engine that implements JSDK 2.0 and higher although our target goal is to work with Tomcat because it supports the newer API features such as WAR files. The development database that will be used is MySQL. Scarab will be using the Object Relational (OR) tool that is built into Turbine called Torque. This tool will abstract out all the SQL by adding a layer on top of JDBC making it possible to use any database without code changes. Schema's specific to Oracle and MySQL will be distributed by default with Scarab. Schema contributions by end users for other databases will also be included. In fact, Turbine's OR tool has recently added support for a templated methodology for generating schema's many of the major RDBM's (with the ability to easily add more).

Database Schema

Our database schema has been developed in a platform neutral way so that it will work on any SQL RDBMS. We are not taking advantage of any specific features of the database. Instead, we are taking advantage of the OR tool that has been developed within the Turbine framework. The Peer tool allows us to abstract all of the specific database features into classes that are auto-generated. The columns, rows and tables become objects that we can easily manipulate. The benefit of doing things this way is that the schema is given room to grow and change while still allowing the core application logic to be abstracted from the database logic. People developing implementations of Scarab in other languages only need to develop an IDBroker which is a well defined methodology for providing efficient auto-increment functionality that is outside of the database.

One goal of Scarab is to be able to translate from a Bugzilla schema to a Scarab schema. Given this requirement, the functionality within the two schema's will remain consistent. For instance, a Milestone in Bugzilla is still a Milestone in Scarab. The only primary differences between the two will be additional features that are required by Scarab and a more thought out and normalized database design.

Usability

We have spent quite a lot of time looking at other issue tracking systems and we have tried to either copy or improve on top of those systems. A really good example of one feature we are excited to add to Scarab (that helps illustrate that we are thinking about this stuff) is a methodology that works like this: The problem we are trying to cut down on is a fairly common problem: duplicate issue reporting. Not only do we want to make it easy to mark an issue as a duplicate, but how about doing something where the user starts to fill out an issue report form and during the process an incremental search is performed for other issues that match the one that you are filling in. That way, the user is presented with a list of issues that potentially match their issue and are given the choice to simply append on to an existing issue instead of creating a whole new one.

Page design and user interface is another factor of usability. Because we are using Velocity and Turbine together, we are providing a way for people to easily customize on a page by page basis the look and feel of Scarab without having to dig into the actual Java code at all. The overall design is templated with easy to modify layout and navigation modules. We have also enlisted the help of UI design expert Cameron Barrett to do a default design of both page flow through the system as well as look and feel.

Scarab's initial goal is to have equal feature functionality to Bugzilla, because Bugzilla is the most used issue tracking system for OSS projects. While Bugzilla is a great step forward from other systems (like GNATS), it is still missing out on a good UI design, code design and database schema design. So, what we have done is start with the concepts in Bugzilla's database schema and identified areas where it can be improved through better design and additional database normalization. Since we are using a web application framework (Turbine) and back end technology (Java vs. Perl), we will also kill the code and design problems inherent in Bugzilla with one stone.

A major problem with Bugzilla is that it is implemented in such a fashion that security is not taken into consideration and this has resulted in being a catalyst for high profiles sites being hacked into (including apache.org). The fact of the matter is that Bugzilla was never meant to be used outside of Netscape and the code shows. When Mozilla.org was created, there was a great hurry to provide some sort of issue tracking system for people to use. Bugzilla was available internally at Netscape and there were people at Netscape that knew how to install and use it. To Mozilla.org's credit (and the contributors to the project), Bugzilla has grown quite a bit, the TCL/TK dependencies were removed, the code has been cleaned up quite a bit, bugs have been fixed and features added. The problem is that this has been done on top of a poorly designed base which is not only hard to setup and configure (the first thing you have to do is change the path to the Perl executable in each and every file!), but also hard to customize the look and feel of because much of the look and feel is hard coded in Perl code. It is time to start over with something new that is designed from the ground up to scale to other people's needs.

Processes

There are some well defined process's within Bugzilla that we do appreciate. For example, the Anatomy of a Bugs Life is a terrific example of how the whole process of dealing with an issue should work. Duplicating these rules within Scarab is a priority as doing it any other way would be simply reinventing the wheel. The point we are trying to convey is that we are encouraging the idea of taking the good pieces and dropping the bad. Another place that we will copy Bugzilla is in their DTD definition. By using the same DTD as Bugzilla, we can more easily implement import/export between Scarab and Bugzilla.

Here is a list of requirements that need to be accomplished by Scarab (at least in the first round):

• submit a new bug (both long form and single page)
• query and modify existing bugs
• manage patches and attachments
• users and roles
• create and remember reports that display metrics
• full web based administration of all aspects of the system
• ability to handle virtual hosting

Scarab is available at any point in time from CVS. In the CVS tree (and the distribution), there is a top level document titled README.txt that explains how to get up and running with Scarab. There is also another documented titled DEVELOPMENT.txt that explains various things that one should watch out for when developing Scarab.

The layout of the top level directory structure in CVS looks something like this:



Within the src/ directory, the structure looks like this:

src/
            conf
            dtd
            html
            i18n
            images
            java/
                org/
                    tigris/
                        scarab/
                            actions/
                            attribute/
                            om/
                            pages/
                            screens/
                            services/
                            tools/
                            util/
            resources
            sql
            templates
                email/
                layouts/
                macros/
                navigations/
                pages/
                screens/
            test
            tomcat-4.0
            usecases

The java/ subdirectory contains all of the Java source code. Within that directory is a package structure that is dictated by Java Coding Standards. The coding standards that will be used by Scarab are the same as what is used in the Turbine Project. The Turbine layout standards which break up the content into various modules such as Screen, Action and Page which are reflected by appropriate directories. The om/ directory is where the Object Model code for Scarab lives. This is the Java code that is mostly auto-generated that performs the database abstraction. The tools/ directory is where the Pull based code will reside. This will be the API for Scarab. The util/ directory is for any utility code that is necessary for Scarab.

The templates/ directory is where all the Velocity templates will live. The directory structure is similar to what is in the java directory structure which mirrors the Turbine module layout.

The sql/ directory contains definition of database schema.

The test/ directory contains the Java source code files related to unit testing for the application (we use JUnit).

The html/ directory contains static web files belonging to project's web application structure. The CSS also lives here as well.

The images/ directory contains static images belonging to project's web application structure.

The conf/ directory contains configuration files for application server and other tools that are running project's web application.

The dtd/ directory contains the Scarab DTD and various other files surrounding the XML import/export functionality.

The tomcat-X.X/ directory contains an appropriate version of Tomcat application server that is used to run project's web application.

Scarab is being designed to be an Issue Tracking System. The primary goal of Scarab is to duplicate Bugzilla functionality, therefore the immediate need is to be able to track a single type of issue: bugs. Regardless of the current requirements, we need to be able to handle our long term needs and thus the schema and overall system design will reflect that need.

Projects/Components

Scarab has the concept of "projects". A project is a container for separating code bases into groups. Within each project is one or more "components". A component is a sub-project within the primary project. For example, ArgoUML is a UML modeling tool. It would have a project titled "ArgoUML". Within that project there are several components such as "GEF", "Documentation", "UML meta-model", "user model", "design history", etc. The purpose of splitting things up like this is to allow developers to "subscribe" to projects and components that they are most interested in while still allowing the system enough flexibility to support multiple uses. In other words, it also allows people to use Scarab to host a multitude of projects under a single Scarab installation.

Within each project, there will be the need to assign an owner of the project. The business logic is that when someone creates a new project, they become the owner of that project. An existing owner can always modify their role within the project. However, they can only associate their ownership to another user in the system. In other words, they cannot be removed from the administrative function unless the Scarab system admin removes it. This is to prevent abuse. The owner of the project has complete control over all aspects of that project and the administrative interfaces will need to provide methods for modifying a projects attributes.

Users/Visitors/Members

Each of these may be used all over the system to mean the same thing. What they mean is a user who has registered with the installation of Scarab. Scarab stores all of the user information in Turbine's TURBINE_USER table. In the future, Scarab may opt to create its own Visitor table with Scarab specific columns or simply create join tables that relate extra information to a user. In order to perform any permanent tasks within Scarab such as creating a new issue, users will be required to create an account. Users who have not logged into the system are still tracked with their own unique session information, but it is lost when it times out due to inactivity. The account can have any login name and password. The only fields that will be required are first name, last name and email address.

Email plays a crucial role in Scarab and having correct email addresses for users is also crucial. There will be a default mechanism for validation of the email address. The way that it works is that once the account is created, the user will receive an email that will have a URL and a special key code in it. The user can then click on the link and enter the special key code into the webpage. This will confirm that the email address is valid and the user will then have full access to the system. If the user attempts to log into the system before they have confirmed their account, they will get the confirm account screen before being allowed to continue. An example of this type of system is the way that Ebay.com registration works.

Roles and Permissions

There will be several different types of users within the system. There is an overall "system admin" who has root privileges over all the administrative functions of the entire system. There will be a "project admin" who has control over the projects that they are in charge of. There will be a "component admin" who has control over a specific component within the system. Each of these roles will have access only to the specific areas of the website that their roles allow. For example, a "component admin" will not be able to modify a project's details, but they will be able to modify a component's details. The most common user will be "mortal" user who can only submit and query for issues. Whether or not the "mortals" can post across projects and components is still up for debate and will probably be a configuration option within Scarab. Currently, Bugzilla does not have that level of control.

Areas of the website that a particular user does not have access to should not be shown and the links to go to those areas should not be displayed. If the user attempts to access one of these areas by entering a URL, the system will redirect them to a login page. The UI design will need to account for the fact that data may or may not exist depending on which user is logged into the system.

The implementation of the access control will be inherited from Turbine's ACL System. The idea being that a user can have one or more roles. Roles are a collection of one or more permissions. Thus, you can either validate access based on their role or their permission. We will also probably have to extend the functionality of Turbine's system to also include Project specific permissions. The details of the implementation of this still need further consideration. For the initial round of Scarab development, the system will error on being less secure with the idea of needing more security further down the road. The idea being that it is easier to lock down something that already exists than to plan for it in advance because it is very difficult to predict the level of control that the application needs beyond the user roles mentioned above.

Virtual Hosting Domains

There is a requirement to allow Scarab to work with a single installation across multiple domains hosted on a single server. In other words, if a user logs into scarab.tigris.org, then that user should be presented with bugs that relate only to scarab.tigris.org. Searches and queries should occur either across multiple domains and projects or within the individual project. This should be controlled as a preference setting within the individual domain. Installations that only have a single domain would be treated as such. The information for these domains is reflected in the Schema. The following schemes need to be supported: http://project.domain/, http://domain/project and http://project.domain/project/.

Email

The role of email within Scarab will be mostly from a sending vs. receiving standpoint. There are other bug tracking systems such as GNATS that give users the ability to send either specially formatted emails or have emails appended to an existing issue. The problem with this is that it is very difficult to get users to format their emails appropriately and it is even more difficult to write a parser to deal with badly formatted emails. In the end, the whole issue becomes increasingly sticky, for example, what do you do with a badly formatted email? Send it back to the user and ask them to resubmit it? While Unix hackers are willing to accept such abuse, the fact of the matter is that regular users are not.

Instead, Scarab is going to circumvent the entire email submission process by simply not initially allowing it. The future plans will be to accept an XML formatted piece of data. This will be implemented with SOAP (or something like it) technology. By using XML, it will be easy to provide the user with a template that they can fill out. It will also be easy to use an existing XML parser such as Xerces to parse the data and perform actions on it including validation. We will take advantage of Bugzilla's DTD for defining a bug.

On the other side, sending email will be a very large part of Scarab. Nearly every "event", such as a modification to an issue will be broadcast to all of the necessary people or (if configured) mailing lists. The emails themselves will be Velocity template files that get processed in order to insert dynamic data. The benefit of this is that the end users of Scarab will be able to customize the default emails as easily as they can customize the look and feel of the website. The emails will contain as many links as necessary that the user can click on to allow actions to be performed. For example, if the user is required to approve something, the user will get an email that states what needs to be approved and provides a single URL to click on that will take them to the website, allow them to log in and then provide a page that will allow them to execute the approval by clicking a single button. The link could also be coded to simply perform the action after login, but we want to provide a way to pre-confirm things before execution in order to provide a level of control over what happens. The emails will also contain helpful information about the processes. For example, if a Milestone has been reached, give direction on what to do next and guide the user as much as possible.

Email will also be used to "bug" developers that they need to perform some action by a certain date and time. For example, any bug that you have assigned to you that is older than some defined amount of time will cause an email to be sent to you that reminds you that you need to be working on this particular bug. It will be possible to log into the system and put the bug into a "sleep" mode for the next period of time.

Attachments/Patches

Attachments can be associated with an individual issue. An attachment can take the form of a simple text diff patch or an entire binary file. The user interface needs to be designed to allow people to choose the type of attachment they are making and deal with it appropriately. The system will need to have a methodology for managing each of the patches. The data from the uploaded information will be stored in the database by default although the table will contain a column that allows patches to be located as a URL resource as well.

Attributes

Attributes are things like Milestone, Priority, Status, Resolution and Severity. The functionality of these as well as the definition is being initially duplicated from Bugzilla. The reason is that it not only a good common design, but it also makes a Bugzilla->Scarab database conversion tool easier to create. The difference between Bugzilla and Scarab in this respect is in the database design. We have identified the fact that nearly all of these attributes are the same thing. Thus, we have provided a normalized schema that accounts for that as well as for the fact that there may be localization issues. For example, we are building in the ability to give each project control over what the definitions are for each of the attributes as well as providing definitions that can be displayed in a particular language depending on which language you have set in your browser. The management of all of the attributes will be through a web based interface. There will be a default set of values for the attributes that are defined in a properties file. Then, each project and component within the system will have the ability to override these defaults and define their own.

The definition of what should happen when a project reaches a particular milestone still needs to be defined. Certainly, email will be sent. :-) There should be some sort of definition of what sequence of events is enforced and how. Someone should not be able to skip milestones unless they have the permission to do so. The reason this has yet to be defined is because we do not have a working system yet to help us define what is best for the users. This is something that comes during user testing.

Voting

Scarab will have a feature that will allow users to vote on which issues are important to them. This should also help project developers to prioritize which bugs are fixed first. There will be screens which display reports based on the votes.

Dependencies

Bugs can depend on one or more other bugs. These can be tracked within Scarab (for example another issue id) or as a URL to another resource. A single issue can have dependencies on more than one issue. It should be possible to display a page that shows the tree or graph of the dependencies. The definition of what should happen regarding dependencies still needs to be discussed. For example, what should happen if one bug depends on another bug and it is closed? A lot of this is already covered in Bugzilla, but it should be eventually restated here for clarification.

Change Tracking

All changes that occur will be tracked. The user who made the change, the time they made the change, etc. This will allow people to view the history of the issue quickly and easily. We should consider providing some sort of graphical view of the changes through creative use of HTML and/or dynamic image generation.

Enhancement/Wishlist Tracking/TODO/Tasks

Part of the UI should have a specific feature for tracking enhancement requests specifically. An enhancement is essentially a issue of type enhancement, but for UI purposes, it would be nice to have a link where someone could click on it and a list of the enhancement requests are displayed. The actual implementation of this UI will be left up to Cameron to decide on what is best.

Support Tracking

This is similar to the above tracking in that it is essentially another type of issue, but it is listed here seperately because the user interface should allow a user to enter a support issue which would allow the developers to track a conversation with a user. It might work something like this:

Imagine a FAQ/support tracking tool with a feature where someone asks a question and it bugs a developer via email until that person either answers the question or assigns the issue to someone else. If the person answers the question, then it will automatically become part of the larger FAQ system. I think that would be a very cool feature, but is essentially beyond the scope of Scarab for Alpha 1.

Integration with Source Version Control (Subversion)

To be discussed further. Essentially, the idea is that Subversion can be provided API's to allow it to send events to Scarab (for example, through SOAP). Scarab can also use the client libraries to communicate directly with Subversion. Since neither project is finished yet, we can only try to consider ideas on how they will be integrated together. One blue sky feature would be to do something like this. Further input here is appreciated.

Initial Experience

When the user first accesses the system, they will be presented with a screen that welcomes them to the system and provides a search interface for finding projects as well as logging in. If the user logs in, then they are presented with their own personalized homepage that remembers various settings such as the projects the user is associated with as well as frequent queries, bugs they want to track, and vote counts. There will need to be a "preferences" area of the site that allows the user to customize what is displayed on this page. The idea is to make it as painless as possible to allow the user to use the system.

When the user selects a project, they will then be able to start a wizard like process of entering their bug. They can also circumvent that process and fill out a single page report, but this loses the nice process that has been described above regarding duplicate issue handling.

Users should also be able to browse the projects in the system as well as the bugs within the project in an ordered fashion. Users should also be able to go directly to a particular bug and view its status quickly and easily.

One complaint about Bugzilla is that the page that is used to fill out a bug is the same page that is used to display the bug, even if the user does not have access to modify the bugs contents. This has an unfortunate side effect of teasing a user into thinking they can modify the contents of the bug, so they spend time changing things only to find out after the fact that they can't modify the bug. We would like to solve this UI issue by simply making fields that cannot be edited static and not displayed as a HTML form.

Instead of requiring users to bookmark pages, we should provide an interface that accomplishes the same goals. Users should be able to bookmark their queries and which issues matter to them. The should be able to access this information from their customized homepage. If a user does decide to bookmark a page, the system should know how to display that page given that the bookmark is fairl valid. Not all pages will be able to be bookmarked without following a link that specificially allows them to bookmark the page. An example of this is on news sites that have a link to allow the user bookmark the page.

Reports/Metrics

It should be possible to easily create reports that track the life cycle of issues within a project. The granularity will be split up at the component level. For example, it will be possible to determine the number of outstanding issues within a project and within that projects specific components. Dependency and Vote reports should also be created. It should also be possible to create metrics across projects such as which project has had the most bugs fixed.

Administration

Links to the administration portion of the website will only be shown when the user has been logged into the system AND they have enough privileges to access that resource. The admin area will need to have the ability to modify all aspects of the database and system easily. There will also need to be various levels of admin interaction depending on which role the user has. The implementation of this will probably be better handled through the use of multiple screens and actions that are specific to the purpose versus trying to hide and show content and actions depending on user roles because of security reasons. The side effect to this may be the duplication of some screen and action code. An interface to manage the virtual domains and their preferences should be created.

Help System

Scarab will have a contextual help system that explains different areas of the system in detail. The idea is that you will be able to click on a link and a small new window will pop-up that displays information pertaining to the process. One design goal for the system is that a help system should really not be needed. It is provided more as a convenience factor. The user should not have to guess at what to do next, the path should be predetermined and clear.
